Description

Friulmac Frimat-EB

Stand-Alone Machine Configured for Stiles Edgebanding Processing

Working Dimensions:

Min-Max Length: 3.5″ – 59″

Min-Max Width: 1.5″ – 7.9″

Min-Max Thickness: 0.5″ – 1.5″

Working Units:

Max Roll Diameter: 2.625″

Independent Glue Spreader: Glue Type – EVA

Automatic Feed Speed Syncronization

Pneumatic Guillotine

Automatic Edge Detection

Rubber Roll Edge Applicators

3 Steel Rolls Edge Fixing

Min-Max Edge Thickness: 0.3mm – 3mm

Max Feed Rate: 49.2 Ft/Min

Cutting Accuracy @ 49.2 Ft/Min: +/- 3mm

Min-Max Edge Height: 14mm – 45mm

Min Edge Length: 60mm

Total Unit Power: 27 kW

Full Load Power: 52 Amp

Working Air Pressure: 6 Bar

Push Button Controls

HMI Control Panel

Safety Enclosure

Current Voltage: 460V 3PH
