MACCHI CO-EX FLEX CO-EXTRUSION LIN

Description

MACCHI CO-EX FLEX CO-EXTRUSION LINE for sale
Equipped witth;
PLASTEX 65/30 D: PLASTEX 80/30 D : PLASTEX 65/30D
COMPREHENSIVE IBC

Materials extruded: LOPE and blends with LLDPE-MDPE-MLL-PP-EVA 9%.
Film Width with die diam. 300 mm min. 850 mm – max. 1700 mm
Film thickness: min. 10 micron – max. 200 micron – gap 1.6 and 2.4 mm
Production capacity: 1,200 mm – thickness: 50 microns: 350 kg / h LOPE
Total height of the plant for cooling ii: 12 m
400 v – 390 kW
Two [2] HIGH PERFORMANCE SINGLE SCREW EXTRUDERS 65 / 30D
Complete with:
– Bimetallic barrel
– Screw nitrided high capacity
nfrared heating and cooling fans
Nr. Two [2] MOTORS AC 74 Kw
– With digital frequency converter.
Two [2] changer PLATE – 65 mm diameter
– Screwed directly to the end flange of the extruder
One []11 SINGLE SCREW EXTRUDER HIGH PERFORMANCE 80/30D
Complete with:
– Bimetallic barrel
– Screw nitrided high capacity
– Sector grooved feed and water cooled
-5 areas with bands of infrared heating and cooling fans
One [1] MOTOR AC 100Kw
– With digital frequency converter.
One [1] changer PLATE – 80 mm diameter
– Screwed directly to the end flange of the extruder
COEXTRUSION HEAD 3 LAYERS COEX flex® TE 502 IBC
cornplete with:
– 300mm diam die; die gap 1.6 mm
– 220/400 range
– Heating divided into zones, all with heating phases in ceramic,
– Group installed on trolley, with integrated system of distribution of the cooling air
COOLING RING ASR3 TYPE DOUBLE STANDARD FLOW
Complete with:
– Fan complete with silencer and air filter
– Connecting pipe
– Fan 15 Kw
– Insert range 250/500
INTERNAL CONTROL COOLING (IBC) TYPE JET 6
integrated in the main control panel,
CONTROL PANEL COEXTRUSION
