Description
DELTECO PE-63 (1998) Swan neck mechanical press
Nominal force: 630 KN
Normal stop position: TDC
Lifting points: 2
Maximum mass of moving part of die: 136 Kg
Max. number of clutches/min in stroke by stroke: 38
Strokes per minute in continuous operation: 100
Minimum travel: 8 mm
Maximum travel: 100 mm
Maximum height of closed die: 340 mm
Slider adjustment: 92 mm
Total stop time: 190 ms
Spindle adjustment: 80 mm.
Safety distance with two hands: 304 mm
Max. r.p.m. Flywheel: 380
Electrical Data:
Installed power: 5.5 KW
Voltage: 380 V.
Clutch/brake:
Max. pressure: 0.588 Mpa
Min. pressure: 0.343 Mpa
Pneumatic System:
Max. pressure: 0.588 Mpa
Min. pressure: 0.440 Mpa
Characteristics of the largest die:
Maximum mass: 275 Kg
Length: 450 mm
Width: 310 mm
Dimensions: 1500 x 1240 x 2810 mm.
Press mass: 4,300 Kg.
