Description

TRUMPF TrumaBend V130

Tonnage: 1300 kN

Stroke: 215 mm (365 mm)

Max. bed-press beam distance (D ‘): 482 mm (632 mm)

Eff. Open height (D): 385 mm (535 mm)

Inclination of beam: ± 10 mm

Bending length (A): 3060 mm

Distance between side frames (B): 2690 mm

Throat (C): 410 mm

Width of bed: 120 mm

Operating height* (E): 1050 mm

Max. Distance in X: 860 mm (1000 mm)

Travel in X axis: 600 mm

Speed of travel in X: 500 mm/s

Travel in R axis: 250 mm

Speed of travel in R: 300 mm/s

Y rapid speed: 200 mm/s

Y operating speed: 1-10 mm/s

Y return speed: 135 mm / s

Drive motor: 15 kW (18,5 kW)

Oil capacity (aprox.): 250 l

Weight: 12950 kg.

Dimensiones: 3640 x 2210 x 2375 (LxWxH)
